Updated version 50W signal source jammer module Matching broadband amplifier module
Description
It is a type of 50W small size updated version signal source module ,the module is a single signal source .It can be used with different types of broadband amplifier modules,depends on the usege environment the 50W signal source module as a anti drone jammer accessories.
According to customer needs, this signal source can be customized to produce signal sources of different frequency bands, such as 400MHz 500mhz 600mhz. The price is not fixed, we will quote in real time according to your needs.
Feature
1. SMA connector with satble current about 1A and the connector is made of high quality metal materials
2. Small size is portable to carry and installation
3. 20W 50W 433MHz 900mhz 1.2GHz 5.2ghz 5.8ghz multiple type offer
4. Can effectively interfere with drones
5. Aluminum alloy shell helps the heat dissipation and keep the device in a low temperature for long time operation
Specifications
| No. | Item | Data | Unit |
| 1 | Frequency | 2.4(Customized) | GHz |
| 2 | Test voltage | 9-16 | V |
| 3 | Current | 1 | A |
| 4 | Output | 50 | W |
| 5 | Gain | 47 | dB |
| 6 | Output stability | 1 | dB |
| 7 | Connector | SMA / Female |
| 8 | Output connector VSWR | ≤1.30 (No power and VNA test) |
| 9 | Power supply wire | Red+Black+Enable wire |
| 10 | Enable Control | High ON Low Off |
| 11 | Out shell Size | 91*40*19 | mm |
| 13 | Weight | 122 | g |
| 14 | Work Temperature | -40~+65 | ℃ |
| 15 | Out shell material | Aluminum |
| 16 | Vibration need | Car load OK |
